Vortech 2005-2008 Ford 4.0L V6 Mustang - Manual (Page 8)

P/N: 4FU020-610
©2008 Vortech Engineering, LLC
All Rights Reserved, Intl. Copr. Secured
06AUG08 v4.1 05MusV6(4FU..610v4.1)
viii
PART NO. DESCRIPTION QTY. PART NUMBER DESCRIPTION QTY.
IMPORTANT: Before beginning installation, verify that all parts are included in the kit. Report any shortages or dam-
aged parts immediately.
2007-2008 Mustang V6, Standard
Part No. 4FU218-630SQ
2E229-600 V2-S ASY, '05 MUS V6 SAT 1
2A036-361 S/C PULLEY Ø3.60" 6-GRV 1
2A046-105 BELT, 5061055 DAYCO 1
1210517 ASY, IDLER PLY SMOOTH 6-RIB 1
4FU020-610 INSTR MANL, '05 MUS V6 1
4FU110-010 P/S RESERV RELOC, '05 MUS GT 1
7P375-075 Ø3/4" HOSE BARB UNION, BRASS 1
7P375-050 Ø3/8" HOSE UNION, BRASS 1
7R001-004 #4 HOSE CLAMP 2
7R001-008 #8 STNLSS HOSE CLAMP 2
7U038-030 HOSE, P/S 3/4'ID 3'
7U032-016 Ø3/8" EFI FUEL HOSE, HI-PSR 3'
7A250-075 1/4-20 x .75" SHCS PLTD 1
7J250-001 1/4" WASHER, SAE, PLTD 2
7F250-021 1/4-20 NYLOCK NUT ZINC PLATED 1
4FU010-010 P/S RELOC BRKT, '05 MUS GT 1
7U100-055 TIE-WRAP, 7.5" NYLON 4
4FU110-644 S/C MTG BRKT ASY, '05 MUS V6 1
2A017-016 PILOT, 6203/5 BRG, 3/8" SCREW 1
2A017-881-02 SPACER, .875"OD x 4.165"L 3
4CJ017-021 SPACER, .625" COIL 4
4FU010-644 MTG PLATE, S/C, '05 MUS V6 1
4FU010-671 BRKT, INTAKE SUPPORT, V6 1
4FU017-182 SPACER, 1.82"L x 1"OD x .391"ID 1
7A375-100 3/8-16 x 1" G5 HHCS, PLT 5
7A375-352 3/8-16 x 3.5" HxHD GR8 1
7C010-220 STUD, M10-1.5 x 220mm 3
7C080-016 M8-1.25 x 16 HxHD 3
7C080-030 M8-1.25 x 30 HxHD CL10.9 4
7F375-016 3/8-16 Hx NUT 1
7G010-150 NUT, IMP M10 RH SL 6 PT 2
7J010-002 10mm WASHER, ZINC PLATED 3
7J375-044 Ø3/8" SAE WASHER, PLTD 8
7R001-008 #8 STNLS HOSE CLAMP 1
4FU112-610 AIR INLET ASY, '05 MUS V6 1
4FU012-010 INLET DUCT “A”, "05 MUS GT 1
4FU012-015 INLET DUCT “B”, '05 MUS GT 1
7R002-056 #56 SAE TYPE “F” SS HOSE CLAMP 1
7S400-200 SLEEVE, Ø4" x 2"L, BLUE 2
7S400-351 REDUCER SLV, Ø4" x Ø3.5" x 2.35"L 1
7R002-064 #64 SAE TYPE “F” SS HOSE CLAMP 5
8H040-235 AIR FILTER, 4.0"FLG x 7.0"L 1
8A003-071 MAF, 3.8"ID, '05 MUS GT 1
7P750-102 Ø3/4"NPT 1" x 90° HSE FIT 1
7P250-048 Ø1/4"NPT x Ø5/8" BARB x 90° 1
7U033-000 Ø5/8" PCV HOSE 2.5'
4FU013-010 COVER, AIR FILTER, '05 MUS GT 1
4FU112-620 DISCH ASY, '05 MUS V6 1
7P218-156 VAC TEE, 7/32", 7/32", 5/32" 1
7R002-016 #16 SAE TYPE “F” SS HOSE CLAMP 5
7R002-044 #44 SAE TYPE “F” SS HOSE CLAMP 1
7R002-048 #48 SAE TYPE “F” SS HOSE CLAMP 1
72275-094 ELBOW, Ø2.75" x Ø3" x 90°· w/1"ID, V6 1
7U030-046 Ø5/32" VACUUM LINE 5'
7U034-016 1" GS HEATER HOSE 1.75'
8D001-001 STD COMPRESS BYPASS VALVE 1
7P100-010 1" HOSE BARB UNION 1
4FU130-626 OIL FEED ASY, '05 MUS V6 1
7U250-090-260 OIL FEED HOSE, 26" x -4 x 90° 1
7P125-004 Ø1/8"NPT x 90° x -4 JIC FTG STL 1
7P250-091 Ø1/4"NPT x 90° x -4 JIC FTG STL 1
7P250-122 Ø1/4" PIPE THRD AN917 TEE 1
7P250-123 Ø1/4"NPT x Ø1-1/2" PIPE NIPPLE 1
4FU130-636 OIL DRAIN ASY, '05 MUS V6 1
7P375-017 Ø3/8" x Ø1/2" BEADED HOSE BARB 1
7R001-008 #8 STNLS HOSE CLAMP 2
7T560-001 CUTTER, 9/16" ROTABROACH 1
7T560-002 ARBOR, ROTABROACH 1
7U030-036 Ø1/2" OIL DRAIN HOSE 1.25'
4FU139-096 PCV/MAF MOD ASY, '05 GT 1
7P375-106 PCV VALVE, FORD, Ø3/8" HOSE 1
7P625-375 REDUCER, Ø5/8" BARB x Ø3/8" BARB 1
7R001-006 #6 STNLS HOSE CLAMP, NARROW 2
7R001-008 #8 STNLS HOSE CLAMP 3
7R002-010 #10 SAE TYPE “F” SS HOSE CLAMP 1
7U032-016 Ø3/8" EFI FUEL HSE HI-PSR .5'
5W018-030 18GA STRD WIRE GREY 1'
5W018-010 18GA STRD WIRE RED 1'
5W018-020 18GA STRD WIRE BLK, UL1015 1'
5W018-080 18GA STRD WIRE BLUE BULK 1'
5W018-090 18GA STRD WIRE BROWN BULK 1'
5W018-100 18GA STRD WIRE PURPLE 1'
5W001-007 Ø3/16" HEAT-SHRINK TUBING 1.5'
5W001-005 Ø3/8" PLASTIC WIRE LOOM 1.5'
5W001-012 18GA BUTT CONN RED INSUL 12
7U033-020 HOSE, 5/8"ID CLASS-1, EMISSIONS .66'
5A003-038 PREDATOR, '07 MUSTANG 1
8F060-048 FUEL INJ, 39LB EV6, OEM '03 COB 6
008110 SMALL SILVER DIE-CUT DECAL 2
008130 LICENSE PLATE FRAME, VORTECH 1
008444 S/C STRT INFO PKG ASY VORTECH 1
PARTS LIST
®
ENGINEERING, LLC
