7. CHARGE AIR COOLER INSTALLATION (H.0. Kits Only), cont’d
G. COOLANT RESERVOIR FILL
1. Check to make sure all previously
installed hose connections are secure.
2. Fill the engine cooling system through
the Vortech supplied coolant reservoir
using the factory coolant previously
drained.
3. Locate the factory coolant reservoir cap
removed in Section 1 and install it on the
Vortech supplied reservoir.
4. CAC cooling system.
a. Temporarily remove the 3/4" hose
attached to the 3/4" x 90° fitting on
the CAC surge tank.
b. Cap the open end of the 3/4" x 90°
fitting using the provided vinyl cap.
c. Fill the CAC coolant using a
25%/75% antifreeze/water mix. Fill
through the 3/4" hose removed from
the surge tank fitting.
d. Fill the system until the coolant level
reaches the surge tank.
e. Remove the vinyl cap from the surge
tank fitting and reinstall the 3/4" hose
previously removed and secure with
the nylon ratchet clamp.
5. Reinstall the front bumper assembly
including the foam inner bumper, all plas-
tic splash panels and light connections in
the reverse order removed.
