Vortech 2005-2008 Ford 4.0L V6 Mustang - Manual (Page 7)

P/N: 4FU020-610
©2008 Vortech Engineering, LLC
All Rights Reserved, Intl. Copr. Secured
06AUG08 v4.1 05MusV6(4FU..610v4.1)
vii
2E229-620 V2-S ASY, '05 MUS. V6 CAC 1
2A036-325 S/C PULLEY, Ø3.25" 6-GROOVE 1
4FH016-150 IDLER PULLEY, 6-RIB Ø3" 1
2A046-105 BELT, 5061055 DAYCO, 6-RIB 1
4FU110-010 P/S RESERV RELOC, '05 MUS GT 1
7P375-075 Ø3/4" HOSE BARB UNION, BRASS 1
7P375-050 Ø3/8" HOSE UNION, BRASS 1
7R001-004 #4 HOSE CLAMP 2
7R001-008 #8 STNLS HOSE CLAMP 2
7U038-030 HOSE, P/S, 3/4"ID 3'
7U032-016 Ø3/8" EFI FUEL HOSE HI-PSR 3'
7A250-075 1/4-20 x .75" SHCS PLTD 1
7J250-001 1/4" WASHER, SAE, PLTD 2
7F250-021 1/4-20 NYLOCK NUT ZINC PLATED 1
4FU010-010 P/S RELOC BRKT, '05 GT MUS 1
7U100-055 TIE-WRAP, 75" NYLON 4
4FU110-644 S/C MTG BRKT ASY, '05 MUS V6 1
2A017-016 PILOT, 6203/5 BRG 1
4FU017-182 SPACER, IDLER SMOOTH 6-RIB 1
2A017-881-02 SPACER, .875"OD x 4.165" LONG 3
4FU010-644 S/C MOUNT PLT, '05 MUS V6 1
4FU010-671 BRKT, INTAKE SUPPORT V6 1
7A375-100 3/8-16 x 1" G5 HxHD PLT 5
7A375-352 3/8-16 x 3-1/2" HxHD 1
7C010-220 STUD, M10-1.5 x 220mm 3
7C080-016 M8-1.25 x 16 HxHD 3
7F375-016 3/8-16 Hx NUT 1
7G010-150 NUT, IMP M10 RH SL 6-PT 2
7J010-002 10mm WASHER, ZINC PLATED 3
7J375-044 3/8"SAE WASHER, PLTD 8
4CJ017-021 SPACER, .625" COIL 4
7C080-030 M8-1.25 x 30 HxHD CL10.9 4
4FU112-610 AIR INLET ASY, '05 MUS V6 1
4FU012-010 INLET DUCT, “A”, '05 MUS GT 1
4FU012-015 INLET DUCT, “B”, '05 MUS GT 1
7R002-056 #56 SAE TYPE “F” SS HOSE CLAMP 1
7S400-200 SLEEVE, Ø4" x Ø2", BLUE 2
7S400-351 SLEEVE Ø4" x Ø3.5" x 2.35"L 1
7R002-064 #64 SAE TYPE “F” SS HOSE CLAMP 5
8H040-235 AIR FILTER, '05 MUS H.O. 1
003-071 MAF WELDED ASY, '05 MUST GT 1
7P750-102 Ø3/4"NPT x Ø1" x 90° HSE FIT 1
7P250-048 Ø1/4"NPT- Ø5/8" BARB 90° 1
7U033-000 Ø5/8" FUEL/PCV HOSE 2.5'
4FU013-010 COVER, AIR FILTER, '05 MUS GT 1
4FU130-626 OIL FEED ASY, '05 MUS V6 1
7U250-090-260 OIL FEED HOSE, 26" -4 x 90° 1
7P125-004 Ø1/8"NPT 90° x -4 JIC FTG 1
7P250-091 Ø1/4"NPT 90° x -4 JIC FTG STL 1
7P250-122 Ø1/4" PIPE THRD AN917 TEE 1
7P250-123 Ø1/4"NPT x 1-1/2" PIPE NIPPLE 1
4FU130-636 OIL DRAIN ASY, '05 MUS V6 1
7P375-017 Ø3/8"NPT x Ø1/2" BEADED HSE BRB 1
7R001-008 #8 STNLS HOSE CLAMP 2
7T560-001 CUTTER, Ø9/16" ROTABROACH 1
7T560-002 ARBOR, ROTABROACH 1
7U030-036 Ø1/2" OIL DRAIN HOSE 1.25'
4FU139-096 PCV/MAF MOD ASY, '05 GT 1
7P375-106 PCV VALVE, FORD, Ø3/8" HOSE 1
7P625-375 REDUCER, Ø5/8" BARB TO Ø3/8" BARB 1
7R001-006 #6 STNLS HOSE CLAMP, NARROW 2
7R001-008 #8 STNLS HOSE CLAMP 3
7R002-010 #10 SAE TYPE “F” SS HOSE CLAMP 1
7U032-016 Ø3/8" EFI FUEL HSE HI-PSR 0.5'
5W018-030 18GA STRD WIRE GREY 1'
5W018-010 18GA STRD WIRE RED 1'
5W018-020 18GA STRD WIRE BLK, UL1015 1'
5W018-080 18GA STRD WIRE BLUE BULK 1'
5W018-090 18GA STRD WIRE BROWN BULK 1'
5W018-100 18GA STRD WIRE PURPLE 1'
5W001-007 3/16" HEAT-SHRINK TUBING 1.5'
5W001-005 3/8" PLASTIC WIRE LOOM 1.5'
5W001-012 18-22GA BUTT CONN RED INSUL 12
7U033-020 HOSE, 5/8"ID CLASS-1 EMISSIONS 0.66'
5A003-035 DIABLO PREDATOR, '05 MUS 1
8F060-048 FUEL INJ, 39LB EV6, OEM 03 COB 6
4FU020-610 INSTR MAN '05 MUS V6 1
008110 SMALL SILVER DIE-CUT DECAL 2
008130 LICENSE PLATE FRAME, VORTECH 1
008444 S/C STRT INFO PKG ASY VORT 1
8N101-620 WELDED CORE ASY, '05 V6 MUS 1
8N155-080 COOLANT RES RELOC, '05 MUS 1
8N055-080 TANK, RAD OVERFLOW, '05 MUS 1
4FU010-051 MTG BRKT “A”, RES RELOC '05 MUS 1
4FU010-061 BRKT “B”, COOL RES RELOC '05 MUS 1
7A250-051 1/4-20 x 50 HHCS ZINC PLTD 4
7P250-045 1/4" MALE NPT x Ø3/8" MALE BARB 1
7J006-093 6mm WASHER, PLATED 4
7R002-010 #10 SAE TYPE “F” SS HOSE CLAMP 1
7P375-050 Ø3/8" HOSE UNION, BRASS 1
7U030-056 Ø3/8" PCV/VAC RUBBER HOSE 2.5'
7R004-002 STEPLESS CLAMP, 170-70 3
7C060-020 M6-10 x 20mm HHCS ZN 3
7J006-093 6mm WASHER, PLATED 3
8N106-130 WATER COOLER ASY, '05 MUS 1
8N006-010 WATER COOLR, SETRAB SINGLE PAS 1
8N010-180 MTG BRKT, CAC RTSIDE, 'O5 MUS 1
8N010-190 MTG BRKT, CAC LSIDE, 'O5 MUS 1
2A017-036 SPACER, PLTBRGH SG, 0186" 4
7C080-030 M8-1.25 x 30 BLT CL88 4
7F008-020 NUT, M8-125 4
7J312-000 5/16" FLAT WASHER-SAE 8
7R003-016 ADEL CLAMP, 10" 1
7J006-093 6mm WASHER, PLATED 2
7F250-021 1/4-20 NYLOCK NUT ZINC PLATED 5
7A250-074 1/4-20 x .75" HHCS PLTD 5
7J250-001 1/4" WASHER, SAE, PLTD 10
8N104-620 SUPPORT PCS, '05 MUS V6 CLR 1
008341 VORTECH CHARGE COOLER DECAL 1
4FE014-010 RADIATOR PIPE, STAINLESS 1
4PCS010-110 MTG BRKT, RES TNK SRT10 TRUCK 1
5W001-009 16-14GA MALE SLIDE INSULATED 1
5W001-011 16-14GA RING TERM 26" HOLE 1
5W001-015 FUSE, BLADE TYPE 20AMP 1
5W001-022 T-TAP CONN, 14-16AWG 1
5W001-032 Ø1/4" PLASTIC WIRE LOOM 60"
5W001-071 FUSE HOLDER, 16GA WIRE 1
5W018-010 18GA STRD WIRE RED 5'
7A250-050 1/4-20 x .50" SHCS ZINC PLTD 3
7A250-051 1/4-20 x .50" HHCS ZINC PLTD 2
7E014-075 #14 x .75" SHEETMETAL SCREW 2
7J006-093 6mm WASHER, PLATED 5
7P218-156 VAC TEE, Ш7/32", Ш7/32", Ш5/32" 1
7P375-075 Ø3/4" HOSE BARB UNION, BRASS 1
7P500-026 Ø1/2"NPT x Ø3/4" BARB 90° BRASS 6
7P500-078 Ø1/2"NPT x Ø3/4" HOSE FIT STRT 1
7P500-750 Ø1/2"NPT x Ø3/4" BARB 90° SHORT 1
7PP100-076 HOSE REDUCER, Ш1" - Ш3/4" MOD 1
7R002-016 #16 SAE TYPE “F” SS HOSE CLAMP 4
7R002-024 #24 SAE TYPE “F” SS HOSE CLAMP 2
7R002-044 #44 SAE TYPE “F” SS HOSE CLAMP 3
7R002-052 #52 SAE TYPE “F” SS HOSE CLAMP 1
7R003-016 ADEL CLAMP, 10" 1
7R003-027 ADEL CLAMP, 1-11/16" 1
7R007-001 NYLON RATCHET CLAMP 1-1/8" 14
7S275-055 ELBOW, Ø2.75" x 55° SILICONE 1
7S300-101 SLEEVE, Ø3" x Ø1", 1-PLY 1
7S325-275 ELBOW, 90° SILICONE 3.25"/2.75" 1
7U030-046 Ø5/32" VACUUM LINE 5'
7U030-065 Ø3/4" x 90° RUBBER HOSE, SHORT 1
7U034-016 Ø1"GS HEATER HOSE 0.5'
7U034-016 Ø1"GS HEATER HOSE 2.25'
7U038-000 Ø3/4" HEATER HOSE 14'
7U038-012 HOSE, Ø3/4" x 90°, 4" x 12" LEGS 2
7U100-055 TIE-WRAP, 7.5" NYLON 6
7U375-054 3/4" VINYL CAP 1
8D001-001 STD BYPASS VALVE 1
8F001-402 PUMP, WATER, PIERBURG 1
8N010-160 SURGE TANK BRKT, '05 MUS GT 1
8N055-030 TANK, WATER, TRIANGLE SHAPE 1
8N055-050 PLASTIC CAP, SURGE TANK 1
8N056-061 SURGE TANK INTEGRA GSR MODIFIED 1
PART NO. DESCRIPTION QTY. PART NO. DESCRIPTION QTY.
IMPORTANT: Before beginning installation, verify that all parts are included in the kit. Report any shortages or dam-
aged parts immediately.
2005-2006 Mustang V6, H.O.
Part No. 4FU218-620SQ/628SQ
PARTS LIST
®
ENGINEERING, LLC
