RVC 2-33 CD &
Appendix
Version 01/2009, Rev. 1.21 of 25/11/2013 - sb 75
Translation of the original operating manual
11.4 Brief Operating Instructions
1. Switch on the system at the mains power switch down on the
right side of the unit.
2. Switch on the cooling trap and/or the vacuum pump.
3. Close the lid.
4. Starting the warm-up phase:
Enter the set values for the warm-up phase into "menu"
"options" "Timer warm-up" und "Temperature warm-up",
confirm your entries and quit the menu.
Press the left-hand function key "mode".
Select the "Warm-up" menu and confirm.
Open the lid when the warm up phase has ended.
Install the rotors and close the lid.
5. Changing the set values for time, temperature, vacuum and
safety pressure:
Select "menu" with the right-hand function key.
Select "Change set values for manual mode" from the main
menu.
Select the set value by using the up/down keys and confirm
with the right-hand function key "edit".
Change the set value by using the up/down keys and confirm
with the right-hand function key "ok".
Quit the menu with the left-hand function key.
6. Starting the process "Evaporation manual" or "Evaporation
program":
Open the menu "Start with phase..." by pressing the left-hand
function key "mode".
Select "Evaporation manual" or "Evaporation program" using
the up/down keys.
Start the evaporation process by pressing the right-hand
function key.
The function "Evaporation program" can only be selected if a
program has been created before.
The start of the evaporation process starts the following automatic
process run:
The rotor speed increases (rotating direction left)
At 70% of the selected maximum speed: the aeration valve
closes automatically (to avoid delays in boiling)
At 80% of the selected maximum speed: the stop valve opens
the connection to the vacuum pump
Further speed increase until the preselected maximum rotor
speed is reached.
