RVC 2-33 CD &
Storage and Transport
Version 01/2009, Rev. 1.21 of 25/11/2013 - sb 21
Translation of the original operating manual
4 Storage and Transport
4.1 Dimensions and Weight
Valures for the rotational vacuum concentrator without a vacuum
pump:
RVC 2-33 CD &
Height: 315 mm
Height with open lid: 715 mm
Width: 390 mm
Depth (incl. vacuum flange
connection) 536 mm
Weight: approx. 44 kg
Fig. 4.1: Dimensions and weight of the rotational vacuum concentrator
without a vacuum pump
4.2 Storage Conditions
In order to ensure the protection against mechanical and climatic
influences, the guidelines of the German Federal Association for
Wooden Packages, Pallets, and Export Packaging (Bundesverband
Holzpackmittel, Paletten, Exportverpackung e.V.), the so-called HPE
packaging guidelines, must be applied when packing and storing the
rotational vacuum concentrator.
The storage must be:
dust-free
dry
free from excessive temperature fluctuations
free from a mechanical load
