RVC 2-33 CD &
Appendix
70 Version 01/2009, Rev. 1.21 of 25/11/2013 - sb
Translation of the original operating manual
Swing-out rotors
The balance point of the loaded bucket must be located considerably below the pivotal point (see chapter Fehler!
Verweisquelle konnte nicht gefunden werden. ff)!
Plate No. of
plates
per
device No. of
plates
per
rotor Dimensions of the plates
W x D x H Setting
angle
(Reference:
vertical) Rotor type / accessories Material Part no.
Basic
rotor Set Accessories
--- --- --- ---
90°
(swinging out
fully)
Swing-out rotor for microtiter plates (MTP),
assay plates (AP) and deepwell plates (DWP) aluminium
black anodized 124511 ---
--- --- --- --- --- Coulpling piece, to connect two rotors no. 124511 aluminium
black anodized --- --- 124553
MTP
or
DWP 12
4 6
2 max. 86,5 x 128,5 x 14,0 mm
max. 86,5 x 128,5 x 53,0 mm
--- Carrier, without bottom window, for 3 microtiter
plates or 1 deepwell plate, suitable for rotor no.
124511 aluminium
black anodized --- --- 141993
MTP
or
AP
or
DWP 12
8
4 6
4
2 max. 86,5 x 128,5 x 15,9 mm
max. 86,5 x 128,5 x 25,9 mm
max. 86,5 x 128,5 x 60,0 mm --- Carrier, without bottom window, for 3 microtiter
platesor 2 half-size deepwell plates or 1 deepwell
plate, suitable for rotor no. 124511 aluminium
black anodized --- --- 124708
Carrier plate with distance piece, red, heigth 6 mm,
suitable for carrier 124708 aluminium
black anodized --- --- 124704
Carrier plate with distance piece, blue, height
16 mm, suitable for carrier 124708 aluminium
black anodized --- --- 124705
DWP 4 2 max. 86,5 x 128,5 x 60,0 mm --- Carrier, with bottom window, for one deepwell
plate, suitable for rotor no. 124510 stainless steel
electropolished --- --- 124450
