RVC 2-33 CD
&
Appendix
Version 01/2009, Rev. 1.21 of 25/11/2013 - sb
71
Translation of the original operating manual
Plate
No. of
plates
per
device
No. of
plates
per
rotor
Dimensions of the plates
W x D x H
Setting
angle
(Reference:
vertical)
Rotor type / accessories
Material
Part no.
Basic
rotor
Set
Accessories
MTP
or
DWP
12
4
6
2
max. 86,5 x 128,5 x 14,0
mm
max. 86,5 x 128,5 x 53,0 mm
90°
1 set, consisting of
2 rotors, part no. 124511
1 coupling piece, part no. 124553
4 carriers, part no. 141993
aluminium
black anodized
---
124550 ---
MTP
or
AP
or
DWP
12
8
4
6
4
2
max. 86,5 x 128,5 x 15,9 mm
max. 86,5 x 128,5 x 25,9 mm
max. 86,5 x 128,5 x 60,0 mm
90°
1 set, consisting of
2 rotors, part no. 124511
1 coupling piece, part no. 124553
4 carriers, part no. 141993
4 carrier plates, part no. 124704
4 carrier plates, part no. 124705
aluminium
black anodized
---
124567 ---
DWP
4
2
max. 86,5 x 128,5 x 60,0 mm
90°
1 set, consisting of
2 rotors, part no. 124511
1 coupling piece, part no. 124553
4 carriers, part no. 124450
aluminium
black anodized;
stainless steel
electropolished
---
124555 ---
