5.22
servo feeds, auxiliary equipment (such as PLCs), a laptop interface for downloading messages, and a
network interface. See the manual pertaining to the particular device that is connected for communication.
Section 5.5 Restricting PLS Outputs
This selection provides the menu shown in Figure 5.12 and allows the user to restrict operator access to
specific programmable limit switch outputs. The arrow keys are used to position the cursor onto the
desired channel and the CHANGE STATUS softkey is used to restrict or un-restrict the selected channel.
Changing the status of a PLS channel to Restricted secures the present setpoint and description
information. The ability to change or bypass the channel will be removed from the display selections
normally available in the programmable limit switch menu. No changes will occur to a restricted channel
if a different job is recalled. Channels that are bypassed before being restricted will automatically return
to normal operation. Only PLS outputs 1-8 can be restricted.
Stroke
Mode Single Stroke
Drive
Speed
Stroke
Speed
SPM
SPM
200
0
Order
Counter
PC STATUS
Counter OFF
RESTRICTED
PLS
CHANGE
STATUS
LIMIT
SWITCH
0 0
Program/Run Switch
TOP
EXIT
Restricted PLS Outputs
Ch Status
1 Restricted
2 un-Restricted
3 un-Restricted
4 un-Restricted
5 un-Restricted
6 un-Restricted
7 un-Restricted
8 un-Restricted
Use 2 2 4 4 Keys to select Channel
Figure 5.12 Restricting PLS Outputs
Section 5.6 Output Names/Messages
This configuration menu allows descriptive information to be programmed into the operator terminal.
Section 5.6.1 Input Names (option)
If the optional expansion card rack and third input card are provided, this menu selection displays the
screen in Figure 5.13. To edit a description position the cursor over the description and press the
CHANGE NAME softkey. The text edit box will appear. After the correct description is entered press
the ENT key. Fifteen inputs (I58-I72) can be assigned a twenty character application specific description
by the user. The type of stop condition and terminal number is shown for each input.
