PE Series Operator’s Manual 34
Mbcfm!Pqujpot
(cont.)
Print Speed Allows the selection of different rates that the label
will be printed.
*6.0 ips
Value range:
model dependent
PE 42; 2 to 10 ips (51 - 254 mm/sec)
PE 43; 2 to 8 ips (51 - 203 mm/ sec)
Slew Speed Allows the selection of different rates that the printer
will feed during non-printed portions of each label.
*8.0 ips
Value range:
model dependent
PE 42; 2 to 10 ips (51 to 254 mm/sec)
PE 43; 2 to 8 ips (51 - 203 mm/sec)
Backfeed Speed Allows the selection of different rates that the printer
will backup labels.
*5.0 ips
Value range:
2.0 -5.0 ips
Range is the same for both models.
Label Width Changes useable label width, as when printing on
media narrower than 4.1 inches; reducing width
increases memory for label formatting. Also allows
printing of Configuration Labels on narrow media.
*410 or
416, respectively
The printer must be reset for the new value to be
recognized.
Value range: PE 42; 100 to 410 (1.00 to 4.10 in.)
PE 43: 100 to 416 (1.00 to 4.16 in.)
Present Position Sets the label’s stop point (Set Form Stop) after
printing. This value is independent of the Offset Bias
value (Start of Print Position), yet must be greater to
have any effect.
*245 At default this function will have no effect on last
label positioning.
Values range:
0 -999 0.00 to 9.99 inches.
