PE Series Operator’s Manual

Lights

Power

This illuminates when the printer is powered ‘on’. A

delay of up to one second is normal at ‘power up’ or ‘power
down’.

Ribbon/Paper This illuminates to indicate a fault in the

media or ribbon path. Rapid flashing indicates a low-ribbon
condition.

Pause This illuminates when the printer is paused and is

‘off’ when the printer is at Ready.

Menu Keypad

Х Ч Ц Ш

The four arrow keys are used to move through

the printer’s menu tree, scroll through options and increment
or decrement certain definable values. In general,

and

move to the next higher or lower menu level, while

and

scroll through the choices within the same level. See

Appendix G.

Enter Selects the option currently displayed.

Shift Used to change fields on certain menu items. (e.g.

Comm Setup/Serial parameters)

LCD Contrast

Allows the user to change the intensity of the display. Use a
small screwdriver to adjust the display contrast. Turning the
potentiometer counter-clockwise increase the contrast.
