44
mode, see panel S 53 (IRRIG CTRL MODE). The program number indexes this
panel (for more details see Section 3.1 and Appendix 3). This panel displays
and allows the setting of the following parameters:
Program Number
Reflects the selected program (can be selected only inside panel C 03). See
Section 5.2.
PreIrrig
The selectable amount of pre-irrigation in time or volume.
PostIrrig
The selectable amount of post-irrigation in time or volume.
5.7.8 SET SECTORS – S 38
Valve 05 Prog 07
Sector 01 Total 03
Value: 00:00:05
SET SECTORS S38
Each valve can be set for the indicated program using this panel. The panel
allows the setting of the sector (label) number for each valve. A value in time or
volume is entered to determine the duration or amount of activation. Once a
value is entered, it is considered assigned to the indicated program and added
to the total number of valves displayed on the panel. To remove valves from a
program simply enter zeros in the value setting. The valve number indexes this
panel. This panel displays and allows the setting of the following parameters:
Valve
Panel index.
Program Number
Reflects the selected program (can be selected only inside panel C 03). See
Section 5.2.
Sector
Selectable sector (label) number for each valve. Unique or similar num-
bers can be assigned to the valves.
Total
Total number of valves assigned to the indicated program.
Value
The selectable irrigation (time or volume) value for the indexed valve.
