31
5.2.11 SECTOR STATE – C 14
Prog 08 Sect 21/21
Set 00:10:30+009:45
Done 00:03:10 13:15
SECTOR STATE C14
This panel displays the state of each sector. Each sector has an electro-valve.
When a particular sector requires irrigation the electro-valve is opened for a
specified period of time. Valve number along with sector label (upper right
corner of display) indexes this panel. This panel contains the following informa-
tion:
Program Number
Reflects the selected program (can be selected only inside panel C 03). See
Section 5.2.
Sect
The first number displayed is the sector number followed by “/” the valve
number assigned to that sector. This parameter indexes the sectors for this
panel.
Set
Displays the set value in time or volume for the selected sector/valve of the
indicated program.
Done
Displays the current point of irrigation in time or volume for the selected
sector/valve of the indicated program.
System clock
NOTE: The sector’s label can be assigned as customized numeric “tags” for all
the Fertigation Controller’s valves. Labels can be specified using panel
S 38 (SET SECTORS). As default, the sector label will be identical to the
corresponding valve number.
5.2.12 FERTILIZ STATE – C 16
Prog 02 Fert 02
Set 40%
Current 20% 13:15
FERTILIZ STATE C16
