24
NOTE:
- If the user is logged in and the operational mode is CONSULTING MODE,
this panel can be accessed anytime and from any panel using the HOME key
as a shortcut.
- The Real Time Clock, pH and EC sensors are always visible regardless of
state.
- Whenever the Fertigation Controller is connected to a PC that runs the specific
application of the fertigation controller on PC in “ON LINE” mode, this
panel displays the label “PCCom” above the controller clock position. In this
case the Fertigation Controller’s keyboard is disabled until the connection is
lost due to different reasons.
5.1.5 SENSORS STATE – C 02
Active Program: 04
06.3pH 1200W/m2
06.4mS 13:15
SENSORS STATE C02
This panel provides an overview of the real time values of the system’s main
sensors. This panel contains the following information:
Active program number
Displays the number of the executing program. If no program is running a
number is not displayed.
pH sensor reading
Solar Radiation sensor reading
EC sensor reading
System clock
5.2 CONSULTING PROGRAM SETTINGS
The following panels allow viewing the program setting of the Fertigation Con-
troller. The program number can be changed only in C 03 with the UP and
DOWN keys. In addition, the TAB key can be used only in C 03 to toggle the
cursor (focus) between the panel number and the program number. The desired
program number can then be entered directly by using the keypad.
