26
REMINDER: In CONSULTING MODE the ESC key can be used as a short-
cut key to access this panel from any panel.
5.2.2 PH STATE – C 04
Prog 08 Ref=06.4pH
S1=05.4PH
S2=05.5PH 13:15
PH STATE C04
The purpose of this panel is to allow the user to inspect the current pH reference
point for a specific program and the real time pH sensor readings. The program
number indexes this panel. This panel contains the following information:
Program Number
Reflects the selected program (can be selected only inside panel C 03).
See Section 5.2.
Ref = Reference or set point pH value for the specified program.
S1 = Real time value of pH sensor 1. This reading applies to the entire process
and is not program specific.
S2 = Real time value of pH sensor 2. This reading applies to the entire process
and is not program specific.
System clock
5.2.3 EC STATE – C 05
Prog 08 Ref=02.0mS
S1=02.0mS SIn=03.2mS
S2=02.1mS 13:15
EC STATE C05
The purpose of this panel is to allow the user to inspect the current EC reference
point for a specific program and the real time EC sensor readings. The program
number indexes this panel. This panel contains the following information:
Program Number
Reflects the selected program (can be selected only inside panel C 03).
See Section 5.2.
Ref = Reference or set point EC value for the specified program.
S1 = Real time value of EC sensor 1. This reading applies to the entire process
and is not program specific.
S2 = Real time value of EC sensor 2. This reading applies to the entire process
