Page 44
Aileron Check
5. Holding the plane in your hands roll the plane to the right. The ailerons should give a signal
to counter this roll direction as shown below.
6. If the ailerons move correctly, then you have the correct ―AIL REV‖ setting.
7. If the ailerons do not follow the correct movement, please
set ―AIL REV‖ in the ―Control Reverse‖ box. You should
now see the correct servo movement after ‗checking‘
reverse.
Elevator check:
8. Holding the plane in your hands tilt the nose up and down. The elevator should give a signal
to counter this tilting motion as shown below:
9. If the the elevator does not follow the correct movement,
Nose UP
Elevator moves down
Elevator moves up
Nose DOWN
FY-3ZT IN AUTO BALANCE MODE
Left wing aileron automatically
moves upwards.
Roll right
Right wing aileron automatically
moves downwards
Right wing automatically moves
upwards
Roll left
Left wing aileron automatically
moves downwards
FY-3ZT IN AUTO BALANCE MODE
