Page 40
FY-3ZT Debugging instructions
The setup of the FY-3ZT can be started once you have finished installing FY-3ZT and the GCS
software.
Autopilot Function
Flight Control Mode Description:
1. There are three flight control modes: Manual, Auto Balance and Automatic navigation mode.
2. You can utilize Channel 5 to determine Flight Control Modes. Use a 3-position switch on
your radio transmitter.
3. Set CH5 to any 3-position switch on your transmitter.
The pulse width of
CH 5
1000-1199μS 1200-1800Μs 1801-2000μS
Function Manual mode Auto Balance mode Automatic
Navigation mode
4. Note: Do not set CH5 to Automatic Control Mode when the Autopilot is on.

Manual mode: This is normal RC manual operation. You have full control over the plane.
The autopilot is DISABLED.

Auto Balance mode: This provides stabilization only. The pilot still has full control over
the direction, altitude and throttle of the plane.

Automatic navigation mode: In this mode, the autopilot will implement the
corresponding automatic control according to the navigation mode which has been set in
the GCS.
