FeiYu Tech FY-3ZT - Manual (Page 18)

GuiLin FeiYu Electronic Technology Co., Ltd.
GuiLin FeiYu Electronic Technology Co., Ltd http://www.feiyudz.cn E-mail: [email protected]
Page 17

If you choose to use the 5.0 volt power from your ESC BEC, you can plug the throttle control
wire directly into the ―THR‖ port. However please ensure that your ESC internal BEC can
supply a minimum of 3.0 A current. We highly recommend that you have an external BEC
instead.

The 5.0 volt External BEC power input is connected to the I/O1 port.
OPTION 1: Activation and Deactivation of safety feature

When the plane is controlled by the remote adapter board, it contains a communication
interruption protection function.

If the autopilot detects communication interruption lasting 20seconds or more, it will enter
into auto return mode and come safely home. This is the Default setting.

You can however deactivate this Safety Feature if you so wish. One reason to for deactivation
is that the aircraft will continue flying the set route even without Data Radio communication.
This way, it can complete its flight mission fully autonomously. Of course it would make
sense to have the mission end at the base station so you won‘t lose your plane!
Safety Deactivation Procedure:
a) Shut down (close) the RC SW:
b) Change the Remote Control mode to ―RC remote control‖:
c) By doing the above, all control is transferred to the GCS. All RC Transmitter controls
have been deactivated.
d) If during the flight mission the Data-link is lost, the plane will not activate RTH. It will
continue the planned flight.

The Safety function can be restored at any time (even in flight):
a) Ensure the link of the Data Radio is OK (you can control the plane by the Data Radio.
b) Change the Remote control mode to "Data radio remote
control"
c) Open ―RC SW‖ . The Safety function is now restored.
OPTION 1: GROUND STATION DIAGRAMME
