Page 15
AUTOPILOT CONNECTION OPTIONS
There are three options when setting up your FY-3ZT system. Please review them all and choose the
one that best suits your needs.
Option 1: Ground Station Controlled Flight
a) In this option, your aircraft is controlled only by the GCS (Figure 1). With this setup you do
not have a RC receiver in the plane (Figure 2).
b) Your RC Receiver is installed at your ground station. The Receiver servo signal output is fed
into the Remote Adapter.
c) The signals received by the Remote Adapter will be converted to digital signals. The Data
Radio system then up-loads these digital commands to your aircraft.
d) The uploading of data to the aircraft does not involve the GCS. The GCS is only used to
monitor telemetry and flight status of the aircraft. GCS involvement in fight control is
minimal.
e) Warning: In Option 1, the Data Radio range will dictate your flight range. Additionally, due
Figure 2: On the aircraft, the radio
modem controls all flight parameters.
No RC receiver is installed in your
aircraft.
Figure 1: At your ground Station, the
signals from your RC Transmitter is
sent to the RC Receiver which is
connected to your computer via the
FY-3ZT Remote Adapter.
