Page 16
to the digital signal conversion and processing, some delay in manual control transmission
will occur. Refer page 13 on notes on data transfer frequency (Hz).
OPTION 1: ON BOARD AIRCRAFT DIAGRAMME
OPTION 1: ADVANTAGE
Option 1 will make on board installation easier since the RC Receiver does not need to be
installed on board.
You save on weight and installation area.
The entire radio and autopilot settings can be carried out at the Ground Station without
involving the aircraft.
Only a 6 channel receiver is required.
OPTION 1: WARNING
AIL Servo
ELE Servo
GPS Module
Data Radio
RUD Servo
THR Servo
5V battery
