Upgrading The Computer
Upgrading the System Memory (RAM) 6 - 7
6
4. Carefully (a fan and cable are attached to the under side of the cover) slide the
component cover in the direction of arrow
, until the arrow aligns with the
unlock symbol.
5. Carefully disconnect the fan cable from point on the mainboard.
6. Remove the component cover and locate the memory socket .
3 4
5 6
7 8
Figure 6 - 5
Component Cover
Removal
4
3
6
5
7
8
