Windows XP Information
E - 48 Setting Up SATA RAID or AHCI Modes
E
6.
Press Enter and select the Strip Size (best set to default).
7.
Press Enter and select the Capacity size (best set to default).
8.
Press Enter to Create Volume.
9.
Confirm the selection by pressing Y.
10. This will now return to the main menu.
Figure E - 28
- RAID Created
11. Select 4.Exit and press Enter, then press Y to exit the RAID configuration menu.
1.
Create RAID Volume
2.
Delete RAID Volume
3.
Reset Disks to Non-RAID
4.
Exit
RAID Volumes:
ID
Name
Level
Strip
Size
Status
Bootable
1
My RAID
RAID0(Stripe)
128KB
149.1GB
Normal
Yes
Physical Disks:
Port Drive Model
Serial
#
Size
Type/Status(Vol ID)
1
HDT722516DLA380
VDK71GTE17AH6K
153.4GB
Member Disk(0)
4
ST380811AS
5PS196TS
74.5GB
Member Disk(0)
Intel(R) Matrix Storage Manager option ROM v6.0.0.1022 ICH8R wRAID5
Copyright (C) 2003-06 Intel Corporation. All Rights Reserved.
[ MAIN MENU
]
[ DISK/VOLUME INFORMATION ]
[
]-Select
[ESC]-Exit
[ENTER]-Select Menu
