Windows XP Information
Setting Up SATA RAID or AHCI Modes E - 45
E
Prepare the following before setting up your Serial ATA hard disks in RAID or AHCI mode:
1.
An operable computer with a floppy drive (to create a SATA RAID/AHCI driver diskette).
2.
The Device Drivers & Utilities + User’s Manual CD-ROM (WinXP).
3.
An external USB floppy disk drive.
4.
The Microsoft Windows OS CD.
5.
A prepared formatted blank 3.5" 1.44MB floppy diskette.
6.
The second hard disk (required for RAID but not required for AHCI) installed in the optional device drive bay
(see page
RAID Array Types
A Mirrored Array (RAID 1) provides full data protection, as data can simply be copied from
a healthy disk to a replacement for any failed disk.
A Striped Array (RAID 0) is NOT fault-tolerant. The failure of one drive will result in the loss
of all data in the array. It is designed to increase disk performance by spreading the I/O load
across the channels and drives.
