Setting Up SATA RAID or AHCI Modes E - 47
E
For RAID Only (for AHCI Mode go to “Windows Setup for RAID & AHCI Modes” on page E - 49 )
1. Press Ctrl + i to enter RAID configuration menu.
2. Select 1.Create RAID Volume and press Enter.
Figure E - 27 - Intel(R) Matrix Storage Manager
3. Specify the RAID volume name and then press Tab or Enter to advance to the next field.
4. Specify the RAID level (RAID 0 or RAID 1 - see Table E - 3, on page E - 44 and “RAID Array Types” on
page E - 45 ) and then press Tab or Enter to advance to the next field.
5. Press Enter and the system will select the physical disks to use.
1. Create RAID Volume
2. Delete RAID Volume
3. Reset Disks to Non-RAID
4. Exit
RAID Volumes:
None Defined
Physical Disks:
Port Drive Model Serial # Size Type/Status(Vol ID)
1 HDT722516DLA380 VDK71GTE17AH6K 153.4GB Non-RAID Disk
4 ST380811AS 5PS196TS 74.5GB Non-RAID Disk
Intel(R) Matrix Storage Manager option ROM v6.0.0.1022 ICH8R wRAID5
Copyright (C) 2003-06 Intel Corporation. All Rights Reserved.
[ MAIN MENU ]
[ DISK/VOLUME INFORMATION ]
[ ]-Select [ESC]-Exit [ENTER]-Select Menu
