System Map: Rear View 1 - 15
Quick Start Guide
1
System Map: Rear View
1
7
4
6
5
8
12
13
14
Figure 1 - 7 - Rear View
1. Camera Angle Switch
2. USB Port Cover (see pages 7 - 24 & A - 4 )
3. Module Cover
4. Rear Component Cover
5. 3 * USB 2.0 Ports
6. 1 External SATA Port
7. DC-In Jack
8. Audio/Video Jacks (See over)
9. RJ-11 Phone Jack
10. RJ-45 LAN Jack
11. Stand
12. Vent/Fan Intake/Outlet
13. Hard Disk Covers
14. Cable Holders (To Secure Audio/Video/
USB Cables etc.)
3
5
12
12
11
14
9 10
Overheating
To prevent your computer from overheating
make sure nothing blocks the vent(s)/fan in-
take(s)/outlet(s) while the computer is in use.
2
13
