1 - 10 Tilting the LCD Screen
Quick Start Guide
1
Tilting the LCD Screen
It is possible to adjust the angle of the LCD screen in order to get the best possible view without glare etc.
1.
Make sure the computer is sitting on a flat even surface.
2.
Grip the computer at the top of the screen with one hand, and use the other hand to pull the stand out until you
hear a click (at about 40 degrees).
3.
The screen angle can safely be adjusted by pushing it back from the top of the screen to tilt it to the appropriate
viewing angle (the stand will push back from 40 degrees to about 90 degrees).
Figure 1 - 4 - Tilting The Screen
Stand Position
The stand position may be adjusted between 40 and 90 degrees. DO NOT PLACE THE STAND IN THE UPRIGHT TRANS-
PORT POSITION AS IT IS VERY UNSTABLE, and not suitable for viewing.
