System Map: Right View 1 - 13
Quick Start Guide
1
System Map: Right View
Figure 1 - 8 - Right View
1. Primary Optical Device Bay (for
CD/DVD Type Device)
2. Headphone-Out Jack
3. Microphone-In Jack
4. S/PDIF-Out Jack
5. Line-In Jack
6. Mini-IEEE 1394a Port
7. RJ-11 Phone Jack
8. 2 * USB 2.0 Ports
9. Speaker
10. DC-In Jack
11. CATV Jack (Enabled with
Optional Mini-PCI TV Tuner
Only)
2
1
Changing DVD Regional Codes
Go to the Control Panel and double-click System >
Hardware (tab), click Device Manager, then click the
+ next to DVD/CD-ROM drives. Double-click on the
DVD-ROM device to bring up the Properties box,
and select the DVD Region (tab) to bring up the con-
trol panel to allow you to adjust the regional code (see
“DVD Regional Codes” on page 2 - 5 ).
DVD region detection is device dependent, not OS-
dependent. You can select your module’s region
code 5 times. The fifth selection is permanent. This
cannot be altered even if you change your operating
system or you use the module in another computer.
3 4 5
6 7 8 9 8
10
11
CD Emergency Eject
If you need to manually eject a CD/DVD (e.g. due to an unex-
pected power interruption) you may push the end of a straight-
ened paper clip into the emergency eject hole. Do not use a
sharpened pencil or similar object that may break and become
lodged in the hole.
