1 - 8 System Map: Top View with LCD Panel Open
Quick Start Guide
1
LED Indicators
The two sets of indicators on the computer display
helpful information about the current status of the
computer. There are also indicators located on the dis-
play panel of the Audio "DJ".
Table 1 - 1 - LED Indicators
*Note: If you have a second battery then a separate in-
dicator will appear for it.
Table 1 - 2 - Audio "DJ" LED Indicators
Icon Color Description
Green Hard Disk Activity
Green
The (optional) Wireless LAN
Module is powered On
Green
The (optional) Bluetooth
Module is powered On
Icon Color Description
Green DC Power is Plugged In
Blinking Green
The Computer is in Standby
Mode
*
Orange The Battery is Charging
Green
The Battery is Fully
Charged
Blinking Orange
The Battery Has Reached
Critically Low Power Status
Red Battery Error
Blinking Orange E-mail Received
Green Number Lock Activated
Green Caps Lock Activated
Green
Scroll Lock Activated (to
activate press Fn & ScrLk)
