ATI Video Driver Controls
C - 10 Display Modes
C
12. One display will be set to 1 (Primary). The displays may be switched as
long as one as set to Primary.
13. To switch from Extended Desktop mode back to Clone mode, first uncheck
the tick box to disable the Extended Desktop (via the settings tab in the
Display Properties control panel -
Figure C - 5 ) and click Apply.
14. Repeat the procedure in “Attaching Other Displays” on page C - 5
(make sure you have selected the appropriate display to get all the ATI
Mobility Radeon X800 options tabs) to return to Clone mode (click the
/ button to enable any displays if necessary).
In this picture the notebook LCD
panel is the primary display, and the
desktop may be extended to any at-
tached displays.
The primary display is indicated with
a
button depressed. Click the
buttons to switch the primary
display.
Figure C - 6
Displays Tab
(Extended Desktop
Mode)
