Modules
7 - 8 The TV Tuner Module
7
The TV Tuner Module
The optional TV Tuner allows you to watch TV, play music CDs, video con-
ference and capture still images and video on your PC.
The TV Tuner comes with a remote control unit, cable and a CD containing
the utility software. Make sure you install the application(s) from any CDs
provided, then consult the guide for full instructions on how to use the TV
Tuner and software.
The CATV-In jack will only be enabled when the TV Tuner module is in-
stalled. Make sure you install the software before connecting the cable.
TV Tuner Remote
The remote control unit
provided with the op-
tional TV Tuner will
only function when the
computer is powered
from the AC adapter,
and not while the com-
puter is powered by
the internal battery.
Point the remote at the
consumer IR trans-
ceiver to change
channels etc.
Figure 7 - 5
TV Tuner Ports
1. CATV Jack
2. CATV Cable
3. Consumer IR
Transceiver
4. Remote
1
2
3
4
