System Map: Top View with LCD Panel Open 1 - 7
1
System Map: Top View with LCD Panel Open
Figure 1 - 4 - Top View with LCD Panel Open
2
5
3
1
4
8
1. Optional Built-In PC
Camera
2. LCD
3. Speakers (Model A -See
Figure 1 - 2 )
4. LED Indicators
5. AP-key Buttons
6. Power Button
7. Built-In Microphone
8. Keyboard
9. TouchPad & Buttons
10. Audio "DJ" Display
Panel (Including LED
Indicators)
Wireless Device
Operation Aboard
Aircraft
The use of any portable
electronic transmission
devices aboard aircraft is
usually prohibited. Make
sure the module(s) are
OFF if you are using the
computer aboard aircraft.
Use the AP-key Buttons
to toggle power to the
WLAN, Bluetooth and
PC Camera modules.
9
6
10
3
3 3
7
5 6
4
