1 - 12 System Map: Left View
Quick Start Guide
1
System Map: Left View
Figure 1 - 7
Left View
1.
3-in-1 Card Reader
2.
Infrared Transceiver
(see page
3.
Speaker
4.
Secondary Device Bay
Release Latch
5.
Secondary (Optional)
Device Bay
6.
RJ-45 LAN Jack
7.
PC Card Slot
3
1
5
2
4
6
7
3-in-1 Card Reader Formats
The card reader allows you to use the most popular digital storage card formats (see be-
low). To remove any inserted cards, click the Safely Remove Hardware icon
in the
Windows taskbar and follow the instructions on page
in order to prevent system er-
rors (DO NOT PULL THE CARD OUT OF THE SLOT).
Secondary (Optional) Device Bay Options
The following are the device options available for the Secondary Device Bay:
Warning: DO NOT attempt to change any device in the bay while the system is pow-
ered on, and make sure it is fully locked in position (see page
2nd Battery
Do not try to startup the
computer from the 2nd
battery only.
MMC (MultiMedia Card)
SD (Secure Digital)
MS (Memory Stick)
3-Mode Floppy Disk Drive
2nd Battery
DVD-Dual OR Combo Drive
2nd Parallel (PATA) Hard Disk Drive
7-in-1 Card Reader
