1.8" Top Case LCD
D - 2 BIOS Setting
D
BIOS Setting
Before using the application (LCDAP.EXE) provided on the Device Drivers
and Utilities CD-ROM to program the files displayed on the 1.8" LCD, you
must enable the setting in the BIOS:
1. Restart the computer and press F2 at startup to enter the BIOS.
2. Use the cursor keys to move to and select the Advanced menu.
3. Use the cursor keys to move to and select I/O Device Configuration menu.
4. Select the Flash Top Case Logo item and press Enter to change the
setting to Enabled (see sidebar note).
5. Press F10 to save the settings and exit the program.
Flash Top Case Logo
This BIOS item allows
you to enable the serial
port for application pro-
gramming of the top
case logo. After pro-
gramming the logo
make sure you reset
the option to “Dis-
abled” (default) other-
wise the serial port will
not work.
Figure D - 2
BIOS Advanced
Menu > I/O Device
Configuration
PhoenixBIOS Setup Utility
Advanced
F1 Help Select Item -/+ Change Values F9 Setup Defaults
Esc Exit Select Menu Enter Select Sub-Menu F10 Save and Exit
Item Specific Help
Advanced
I/O Device Configuration
Flash Top Case Logo: [ Enabled ]
Serial port A: [Enabled]
Serial port B: [Enabled]
Mode: [FIR]
Parallel port: [Enabled]
Mode: [ECP]
Disable:
Normal serial port A
function.
Enable:
Enables serial port A
for programming the top
case logo image.
Any serial port device
will not be able to
work when this setting
is enabled.
BIOS Menus
The BIOS menus
shown are for refer-
ence only. Your com-
puter’s menus will
indicate the configura-
tion appropriate for
your model and op-
tions (and are subject
to update).
