System Map: Front & Rear Views 1 - 11
Quick Start Guide
1
System Map: Front & Rear Views
1
2
1
6
Figure 1 - 6
Front & Rear Views
1. LCD Latches
2. Audio "DJ" Player
Controls
3. Audio "DJ" LED
4. Speakers
5. Consumer Infrared
Transceiver (Works
with Optional TV
Tuner Remote
Control)
6. DVI-Out Port
7. Parallel Port
8. 2 * USB Ports
9. S-Video-Out Port
10. PS2 Port
11. Serial Port
12. Vent/Fan Intake
13. Security Lock Slot
Overheating
To prevent your computer from overheating make sure nothing blocks the vent(s)/fan intake(s)
while the computer is in use.
2
8 9 7
12
Audio "DJ" Player
The built-in standalone audio CD player gives you direct hardware control for audio CDs (MP3
compatible) when the computer is shut down, but has a working power source.
3
11
4 4
5
10
13
