Upgrading The Computer
Changing the Secondary Bay Device 6 - 9
6
Changing the Secondary Bay Device
1. Turn off the computer, and turn it over and remove the battery.
2. Move and hold the secondary bay release latch (on the left side of the
computer) in the direction of the arrow.
3. Pull the device out of the bay while gripping it at point .
4. When inserting a new device make sure it is pushed fully into the slot until
the release latch
clicks down to lock the device in position.
Secondary Bay
Hard Disk Option
Note that the Second-
ary (Optional) Device
Bay supports parallel
(PATA) hard disks
only.
Figure 6 - 7
Secondary
(Optional) Bay
Device Removal
1
2 3
1
1
3
2
