Section - Configuration
The Layout
There are six different layouts available, as shown below, for the display windows in the monitor program. You can
select between 1 camera, 4 camera, 6, camera, 9 camera, 13 camera, and 16 camera layout. You can select one of
them by clicking on a layout icon. In each layout, you can drag and drop the “channel number” to any display window
in the video area. Following the procedures described in the section titled “Show the video of a specified channel”, you
can add the video channels to display windows within the selected layout in the video area one by one. You can also
exchange the video between different display windows by dragging and dropping. Double clicking on a display window
will switch to single channel layout.
When you choose the one-channel layout or four-channel layout, the “Page up” and “Page down” buttons will be shown
in the left-bottom corner of the video area. You can use these two buttons to switch the pages, as shown in the figure
below.
