Section 1 - Product Overview
Hardware Overview
Antenna Connector
One antenna is included with the DCS-5220. It is fastened onto the antenna connector located on
the back panel, which is used to provide a connection with a wireless network.
Power LED
As soon as the power adapter is connected to the camera, the red LED and the green LED light will both appear
steady on. As the camera is booting, a flashing red LED and steady green LED light will appear next.
The red LED will be turned off during self-test. Upon passing the self-test, a steady red LED and flashing
green LED light will appear, indicating a good connection to the Ethernet port.
Microphone
The DCS-5220 Internet Camera has a built-in internal
microphone.
