D-Link DCS-50 User Manual
Section - Configuration
Checking this will trigger recording while the digital input is high. The technical name for this event is
line trigger.
Checking this will trigger recording while the digital input is low. The technical name for this event is
line trigger.
Checking this will trigger recording while the digital input is changing from low to high. The technical
name for this event is edge trigger.
Checking this will trigger recording while the digital input is changing from high to low. The technical
name for this event is edge trigger.
High:
Low:
Rising:
Falling:
Schedule modes
If you select Continuous mode in the schedule mode selector, it will record continuously during the schedule that is
set up by the user.
Secondary Schedule
Secondary schedule is for recording outside of the primary schedule. The secondary schedule provides options to
record without a specified date or time.
Schedule in Continuous mode
There are three modes in the secondary schedule: Disable, Event mode, and Continuous mode. If event mode is
selected in the secondary schedule, the camera will record whenever an event is triggered. If continuous mode is
selected, the camera will begin recording continuously after scheduling settings are saved. These two modes are the
same as the primary schedule. Please refer to the previous section for more detail.
