Carrier 48SX024-048 - Manual (Page 8)

RIGHT SIDE VIEW
REQ'D CLEARANCES FOR SERVICING in. (mm)
Duct panel ... . . 0
Unit top 36(914)
Side opposite ducts 36 (914)
Compressor access 36(914)
(Except for NEC requirements)
REQ’D CLEARANCES TO COMBUSTIBLE MATL in (mm)
Maximum extension of overhangs
Unit top
Duct side of unit .
Side opposite ducts . .
Bottom of unit .
.
Flue panel ...
NEC REQ’D CLEARANCES in (mm)
Between units, control box side
Unit and ungrounded surfaces, control box side
Unit and block or concrete walls and other grounded
surfaces, control box side
7/8' C22.2) DIA.
CONTROL ENTRY
. 48 (1219)
14 (356)
. 0
9 (229)
. . 0
30 (762)
42 (1067)
36 (914)
42 (1067)
EVAP COIL
OPTIONAL RETURN
AIR OPENING
^1 13/16'
C46.2)
. 17 1/16'
(433.9)
OPTIONAL SUPPLY
AIR OPENING
1 1/4 (31.8) DIA
ALTERNATE POWER ENTRY
7/0 (22.2) DIA
ALTERNATE LV ENTRY
COMPRESSOR ACCESS PANEL
• 1 5/8' (41.3) DIA
GAS ENTRY
1/2' - 14 NPT
GAS CONNECTION
REAR VIEW
UNIT
ELECTRICAL
CHARACTERISTICS
UNIT WEIGHT
CORNER WEIGHT
(Ib/kg)
lb kg A B C D
488X042060,080 208/230-1-60 391 178 100/45 91/41 120/55 80/36
488X042100,120 208/230-1-60 403 183 103/47 94/43 123/56 83/38
48SX048080 208/230-1-60 422 192 109/50 85/39 158/72 70/32
48SX048100/120/140 208/230-1 -60 434 197 112/51 88/40 161/73 73/33
UNIT
CENTER OF GRAVITY (in./mm)
X Y Z
48SX042060,080 26 66/677 21 19/538 15 35/390
48SX042100,120 26.61/676 21.21/539 15 35/390
48SX048080 28 45/723 19.95/507 15.35/390
48SX048100/120/140 28.35/720 19 99/508 15 35/390
LEGEND
CG — Center of Gravity MAT’L —
COND — Condenser NEC —
LV - Low Voltage REQ’D -
Material
National Electrical Code
Required
NOTE: Clearances must be maintained to prevent recirculation of
air from outdoor-fan discharge
Fig. 8 — 488X042,048 Without Base Rail, Unit Dimensions
