OPTIONAL RETURN
AIR OPENING
REQ’D CLEARANCES FOR SERVICING In. (mm)
0
36 (914)
36 (914)
36 (914)
Duct panel
Unit top
Side opposite ducts
Compressor access ......................
(Except for NEC requirements)
REQ’D CLEARANCES TO COMBUSTIBLE MAIL in (mm)
Maximum extension of overhangs ... 48 (1219)
Unit top . 14 (356)
Duct side of unit 0
Side opposite ducts 9 (229)
Bottom of unit ... 0
Flue panel . . .30 (762)
NEC REQ’D CLEARANCES in (mm)
Between units, control box side
42 (1067)
Unit and ungrounded surfaces, control box side 36 (914)
Unit and block or concrete walls and other grounded
surfaces, control box side
. . . . 42 (1067)
Í n/16'
(43.2)
3/16
(46 2)
LEGEND
-17 1/16'-
I (433 9)
LOPTIONAL SUPPLY
AIR OPENING
CG - Center of Gravity MATL - Material
COND — Condenser NEC — National Electrical Code
LV — Low Voltage REQ’D - Required
NOTE; Clearances must be maintained to prevent recirculation of
air from outdoor-fan discharge
7/8* (22.2) OIA
CONTROL ENTRY \ 1 1/0' C20 6) OIA.
POWER ENTRY FLUE HOOD
1 5/8' (41 3) DIA 2 5/16^
GAS ENTRY (58.0)
1/2' - 14 NPT
GAS CONNECTION
FLUE PANEL
0 7/0' (22.23)
ALTERNATE LV ENTRY
EVAP COIL ACCESS
1 1/4' (31.75)
^ALTERNATE POWER ENTRY COMPRESSOR ACCESS PANEL
2 3/16
(55 6)
LEFT SIDE VIEW
UNIT
ELECTRICAL
CHARACTERISTICS
UNIT WEIGHT
CORNER WEIGHT
(Ib/kg)
UNIT HEIGHT
(in./mm)
lb kg A B C D E
48SS180040 208/230-1-60 272 123 81/37 62/28 76/35 53/24 24 1/613
48SS024040 208/230-1-60 303 138 97/44 43/20 123/56 40/18 24 1/613
48SS024080 208/230-1-60 315 143 100/45 46/21 126/57 43/20 24.1/613
48SS030040 208/230-1-60 320 145 100/45 47/21 126/57 47/21 24 1/613
48SS030060/080 208/230-1-60 324 147 94/43 63/29 115/52 52/24 24 1/613
48SS036060/080 208/230-1-60 336 153 86/39 76/35 111/50 63/29 24.1/613
48SS036100/120 208/230-1-60 348 158 89/40 79/36 114/52 66/30 24 1/613
48SS042060/080 208/230-1-60 375 170 95/43 86/39 119/54 75/34 28.1/714
48SS042100/120 208/230-1-60 387 176 98/45 89/40 122/55 78/35 28 1/714
UNIT
F
In./mm
G
In./mm
CENTER OF GRAVITY In./mm
X Y Z
48SS018040
163/16/420 7 18's/i6/481.0
25 07/637 20 59/523
10 85/276
48SS024040 27 07/688 23.35/593
48SS024060 26.98/685 23 27/591
48SS030040 26.71/678 23 46/596
48SS030060/080 27 15/689 22.36/568
48SS036060/080 27.50/698 22.48/571
48SS036100/120 27 40/696 22 44/570
48SS042060/080
203/16/522.3 22'5/ie/582.6
27.01/686 22 44/570
12 7/321
48SS042100/120 26.94/684 22 44/570
Fig. 2 - 48SS018-042 Without Base Rail, Unit Dimensions
