TeeJet Swath XL SmartPad II - Manual (Page 42)

2-20 Chapter 2 - Software Overview
Communications Setup
Fieldware for Smartpad II
Software Version 4.03
Unit
The Unit menu item defines the SmartPad II measurement system. There are two choices, US and Metric. The unit set
in this menu field will effect the entire SmartPad II software suite.
To change the System Unit; highlight the Unit menu item and press . The System Unit dialog box will appear.
Select the desired unit setting using the arrow keys , once the desired unit is selected, press to return back
to the System setup menu, see Figure 2-21.
Figure 2-21: The Unit Menu Item
Setting Description
US All units will be entered and displayed in Feet, Miles, Acres and US volumes. This is
the default setting.
Metric All units will be entered and displayed in Meters, Kilometers, Hectare and Metric vol-
umes.
Table 2-8: The Unit Menu Item Settings
