TeeJet Swath XL SmartPad II - Manual (Page 142)

4-6 Chapter 4 - Waypoint Navigation
Lightbar Setup
SmartPad II
Software Version 4.03
Use Lightbar
Allows the user to turn the lightbar on or off.
To change the Use Lightbar setting; highlight the Use Lightbar menu item and press . The Use Lightbar dialog
box will appear. Select the desired setting using the arrow keys , once the setting is selected, press to
return back to the Lightbar setup menu, see Figure 4 -5.
Figure 4-5: Setup Lightbar Use Lightbar?
Setting Description
No The lightbar will not be used while Nav 2 Point is running. The lightbar will
not be required to run Nav 2 Point.
Yes The lightbar will be used, and will be required while the Nav 2 Point program
is running.
Table 4-1: Use Lightbar Settings
