Instruction Manual

50

Specifications

SV441HDIE

SV841HDIE

SV1641HDIE

Number of Ports

4

8

16

Console

Connectors

(Local)

2 x PS/2 female

1 x DE-15 VGA female

1 x RJ45

1 x DB9 serial male

1 x DC power connector

1 x R-Port

Host Connectors
(Per Port)

1 x DE-15 female

LEDs

Sys OK, R-Port, LAN

Maximum

Number of

Simultaneous

Users

1 active plus 3 viewing

Maximum Video

Resolution

1600x1200 @ 85Hz (Remote)

1920x1440 (Local)

Security

128-bit SSL

Ethernet

10/100 BaseTX

Cascadable

Yes (Master only)

Rack Mountable

Yes

Supported

Interfaces

PS/2, USB (Host) / PS/2 (Console)

Power Adapter

12V DC, 3000mA, center positive

Dimension

(LxWxH)

185.5mm x

224.5mm x

43.2mm

404.0mm x

224.5mm x

43.2mm

404.0mm x

224.5mm x

43.2mm

Weight

2520g

3950g

4150g
