Instruction Manual

12

Main Menu selections

NOTE: Some of the following items may not be present, based on assigned user

privileges (i.e. non-admin users will not see any items under the Admin category).

The Home screen offers a Screen Thumbnail view of the controlled computer, as well

as basic file transfer functions, Monitoring Information, System Identification and VNC

Client options.

The Preferences screen offers several configuration options, pertaining to the

functionality of the IP KVM switch. Here, you will be able to customize settings to

optimize overall performance, (i.e. Encryption options, VNC options, display and

bandwidth options etc.), according to each user’s individual preferences. Please save

your selections by clicking the Save Changes button.

The Snapshots screen allows you to view and save a screenshot of the controlled

computer in its current state. This screenshot will update periodically (automatically).

Saved image files are stored in .PNG format.

Clicking on Logout will terminate your Web Interface section. To re-initiate the Web

Interface, you will be required to re-enter your username and password.

To launch or disconnect a Virtual Network connection with the controlled computer,

click on Connect or Disconnect as appropriate.

The Admin functions allow you to access all of the features you will need to perform

an initial configuration of the IP KVM switch.

Home

Preferences

Snapshots

Logout

Network Config

VNC

Connect

Disconnect
