KIT APPLICATIONS
Prior to installing a high static drive kit (HSDK), always review these installation instructions to ensure the proper application
of the kit for the appropriate equipment to be upgraded and verify that the kit will operate at the desired airfl ow requirements.
For retrofi t/replacement installations, it is recommended that the current systems airfl ow and external static pressure be
attained through on-site test measurements and/or the applicable manufacture’s airfl ow data be reviewed prior to ordering.
Knowing the existing unit performance can greatly increase the reliability of initial system setup calculations in accounting
for other airfl ow losses due to additional accessories and the current duct system performance.
R6GN & GR4GM SERIES UNITS
UNIT MODEL #
RANGE
(IN-WG)
BLOWER
CHART
HSD
KIT
-150C-180C
1.1 - 1.9 PAGE 27
918799
-150C-270C
-150D-180C
920637
-150D-270C
-180C-270C
1.1 - 1.9 PAGE 28 918800
-180C-315C
-180D-270C
-180D-315C
R6GP SERIES UNITS
UNIT MODEL #
E.S.P. RANGE
(IN-WG)
DOWNFLOW
BLOWER CHART
DOWNFLOW
KIT
HORIZONTAL
BLOWER CHART
HORIZONTAL
KIT
-072C-100C
0.8 - 1.6
PAGE 15 920609 PAGE 16 920609
-072C-166C PAGE 17 920609 PAGE 18 920613
-072D-100C PAGE 15 920560 PAGE 16 920560
-072D-166C PAGE 17 920560 PAGE 18 920618
-090C-200C
0.8 - 1.6 PAGE 19 920607 PAGE 20 920607
1.2 - 2.0 PAGE 29 920559 PAGE 29 920559
-090D-200C
0.8 - 1.6 PAGE 19 920606 PAGE 20 920606
1.2 - 2.0 PAGE 29 920558 PAGE 29 920558
-120C-235C
1.1 - 2.0
PAGE 31 920395 PAGE 32 920395
-120D-235C PAGE 31 920396 PAGE 32 920396
P6SP SERIES UNITS
UNIT MODEL #
E.S.P. RANGE
(IN-WG)
DOWNFLOW
BLOWER CHART
DOWNFLOW
KIT
HORIZONTAL
BLOWER CHART
HORIZONTAL
KIT
-072C
0.8 - 1.6
PAGE 11 920609 PAGE 12 920609
-072D PAGE 11 920560 PAGE 12 920560
-090C
0.8 - 1.6 PAGE 13 920607 PAGE 14 920607
1.2 - 2.0 PAGE 21 920559 PAGE 22 920559
-090D
0.8 - 1.6 PAGE 13 920606 PAGE 14 920606
1.2 - 2.0 PAGE 21 920558 PAGE 22 920558
-120C
0.9 - 2.0
PAGE 23 920395 PAGE 24 920395
-120D PAGE 23 920396 PAGE 24 920396
Q6SP & Q5SN SERIES UNITS
UNIT MODEL #
E.S.P. RANGE
(IN-WG)
DOWNFLOW
BLOWER CHART
DOWNFLOW
KIT
HORIZONTAL
BLOWER CHART
HORIZONTAL
KIT
-090C
1.1 - 2.0
PAGE 25 920394 PAGE 26 920394
-090D PAGE 25 920608 PAGE 26 920608
-120C
0.9 - 2.0
PAGE 23 920395 PAGE 24 920395
-120D PAGE 23 920396 PAGE 24 920396
Table 2. Kit Applications
