R6GP-090*-200C MSD kits:
920607 (208-230V, 3Ø, 60 Hz)
920606 (460V, 3Ø, 60 Hz)
Downfl ow Performance Chart ‡ Indicates Factory Sheave Setting for Pre-confi gured Units
External
Unit Static
(in-Wg)
Operating @
230 or 460
Volts
Adjustable Motor Sheave Setting
Fully
Closed
1/2 Turn
Open
1 Turn
Open
1.5 Turns
Open
2.0 Turns
Open ‡
2.5 Turns
Open
3.0 Turns
Open
3.5 Turns
Open
4.0 Turns
Open
4.5 Turns
Open
5.0 Turns
Open
5.5 Turns
Open
6.0 Turns
Open
0.8
CFM 3198 3056 2914
RPM 1078 1056 1033
kW 1.86 1.70 1.54
0.9
CFM 3259 3013 2877 2741
RPM 1110 1080 1058 1036
kW 1.94 1.77 1.62 1.47
1.0
CFM 3240 3047 2853 2708 2563
RPM 1144 1113 1082 1060 1038
kW 1.92 1.81 1.69 1.51 1.33
1.1
CFM 3431 3244 3056 2862 2667 2491
RPM 1205 1176 1146 1116 1085 1063
kW 2.32 2.07 1.82 1.67 1.51 1.38
1.2
CFM 3294 3096 2898 2677 2456
RPM 1207 1178 1148 1117 1086
kW 2.16 1.98 1.79 1.62 1.45
1.3
CFM 3298 3113 2917 2721
RPM 1239 1210 1181 1151
kW 2.24 2.05 1.89 1.72
1.4
CFM 3348 3147 2946 2742
RPM 1271 1242 1213 1184
kW 2.39 2.14 1.88 1.71
1.5
CFM 3182 2966 2750
RPM 1274 1245 1215
kW 2.32 2.06 1.80
1.6
CFM 3433 3230 3026 2804
RPM 1330 1304 1277 1249
kW 2.57 2.36 2.15 1.96
Values include losses for: Unit Casing, 2” Disposable Filters, Dry Evaporator Coil & Installed Heat Exchanger
Values shown refl ect operation at 230V or 460V. For operation at 208V, deduct 0.025 from unit static.
3862
Indicates a recommended unit operational point 1159
3.03
3493
Indicates an allowable setting that is not recommended for unit operation †
† These operational points should be carefully examined by the installer for proper unit setup and heater operation if used.
1017
2.07
Indicates a setting that is not permitted for unit operation
Table 15. Blower Performance for R6GP-090*-200C Units
(7.5 Ton Downfl ow Models Only)
