56
Field PC Owner’s Manual
Product Specifications
Operating System Microsoft ® Windows Mobile ® 6
Processor Intel ® XScale ® PXA270, 624 MHz
Memory 128 MB RAM
Primary Storage 512 MB
Display 3.5” (89 mm) QVGA active matrix
color TFT transflective LCD with LED
backlight; 240 x 320 pixels
Touchscreen Sealed, resistive, pressure sensitive,
enable/disable
Micro SD Card Slots Micro SD header 3.3 V; user accessible
Keyboard
Nine-way directional button, standard
key functions
Operating
Temperature
–4° to 122° F (–20° to 50° C)
Storage
Temperature
–22° to 140° F (–30° to 60° C)
Battery Charging
Temperature
32° to 104° F (0° to 40° C)
Dust proof, water
proof rating
IP67 Sealed rating, waterproof and
dustproof
Batteries Intelligent, rechargeable Li-Ion battery
pack,
I/O Module Serial port 9-pin D-sub connector, USB
Host (Full A), USB Client (Mini B), 12
VDC jack for power input and battery
charging
COM 1 Port 9-pin D-sub connector; full modem
control signals, 5 V @ 200 mA available
on DTR pin 4; controlled by DTR
signal; conformal coated
Current Limits USB Host: 5 V; 9-pin D-sub connector:
5 V on DTR line; recommended
maximum combined output current:
500 mA; short circuit protected
