-255-
be
Default PHB(DSCP 0) for best effort traffic
cs1
Class Selector PHB CS1 precedence 1(DSCP 8)
cs2
Class Selector PHB CS2 precedence 2(DSCP 16)
cs3
Class Selector PHB CS3 precedence 3(DSCP 24)
cs4
Class Selector PHB CS4 precedence 4(DSCP 32)
cs5
Class Selector PHB CS5 precedence 5(DSCP 40)
cs6
Class Selector PHB CS6 precedence 6(DSCP 48)
cs7
Class Selector PHB CS7 precedence 7(DSCP 56)
ef
Expedited Forwarding PHB(DSCP 46)
va
Voice Admit PHB(DSCP 44)
cos
Specify class of service
S pecific class of service
dpl
S pecify drop precedence level
S pecific drop precedence level
Default:
0
Usage Guide:
To configure the DSCP-Based QoS Ingress Classification
Example:
To configure the DSCP-Based QoS Ingress Classification (DSCP: 44, QoS Class: 6, DPL: 2)
Switch# configure terminal
Switch (config)# qos map dscp-cos va cos 6 dpl 2
4.2.153 qos map dscp-egress-translation
Command:
qos map dscp-egress-translation { | { be | af11 | af12 | af13 | af21 | af22 |
af23 | af31 | af32 | af33 | af41 | af42 | af43 | cs1 | cs2 | cs3 | cs4 | cs5 | cs6 | cs7 | ef |
va } } to { | { be | af11 | af12 | af13 | af21 | af22 | af23 | af31 | af32 | af33
| af41 | af42 | af43 | cs1 | cs2 | cs3 | cs4 | cs5 | cs6 | cs7 | ef | va } }
qos Quality of Service
map
Global QoS Map/Table
dscp-egress-translation
Map for dscp egress translation
S pecific DSCP
af11
Assured Forwarding PHB AF11(DSCP 10)
