-221-
| GigabitEthernet
mac MAC table entries/configuration
address-table
MAC table entries/configuration
static
Static MAC address
48 bit MAC address: xx:xx:xx:xx:xx:xx
vlan
V LAN keyword
VLAN IDs 1-4095
interface
Select an interface to configure
*
All switches or All ports
GigabitEthernet
1 Gigabit Ethernet Port
10GigabitEthernet
10 Gigabit Ethernet Port
Default:
300
Usage Guide:
To configure Static MAC Address Table
Example:
To configure Static MAC Address Table as below table
Switch# configure terminal
Switch (config)# mac address-table static 00:11:22:33:44:55 vlan 1 interface
GigabitEthernet 1/1
4.2.106 monitor destination
Command:
monitor destination interface 10GigabitEthernet | GigabitEthernet
monitor Set monitor configuration
destination
The destination port. That is the port that trafficed should be mirrored to
Default:
Disabled
