C-PRO KILO HARDWARE MANUAL
Page 30
JF:
Expansion unit power supply connector
Conn.
Abbrev.
Description
JF-1
V
≅
Expansion unit power supply (24 VAC/20 … 60 VDC)
JF-2
V
≅
Expansion unit power supply (24 VAC/20 … 60 VDC)
JG:
Control unit connection connector (IntraBus)
Conn.
Abbrev.
Description
JG-1
VDC
Power supply (not used)
JG-2
GND
Common ground
JG-3
DATE
Live serial port
JG:
Connector for remote keypad and I/O expansion unit (CAN)
Conn.
Abbrev.
Description
JG-1
CAN+
Connector for the serial CAN+ connection
JG-2
GND
Ground reference connection
JG-3
CAN-
Connector for the serial CAN- Connection
JM-JL-JI-JH
: Digital output connection (electromechanical relays)
Conn.
Abbrev.
Description
JM-4
NO1
Relay No. 1 contact normally open
JM-3
CO1
Relay No. 1 common ground
JM-2
NO2
Relay No. 2 contact normally open
JM-1
CO2
Relay No. 2 common ground
JL-4
NO3
Relay No. 3 contact normally open
JL-3
CO3
Relay No. 3 common ground
JL-2
NO4
Relay No. 4 contact normally open
JL-1
CO4
Relay No. 4 common ground
JI-4
NO5
Relay No. 5 contact normally open
JI-3
CO5
Relay No. 5 common ground
JI-2
NO6
Relay No. 6 contact normally open
JI-1
CO6
Relay No. 6 common ground
JH-3
NO7
Relay No. 7 contact normally open
JH-2
NC7
Relay No. 7 contact normally closed
JH-1
CO7
Relay No. 7 common ground
