C-PRO KILO HARDWARE MANUAL
Page 13
JA Connector for analogue signals
Conn. Abbrev. Description
JA-1 AI1 Analogue input No.1 (for NTC probes)
JA-2 AI2 Analogue input No.2 (for NTC probes)
JA-3 AI3 Analogue input No.3 (for NTC probes)
JA-4 AI4 Analogue input No.4 (for NTC probes/0-20 mA transducers/4-
20 mA transducers); 0-5 V ratiometric transducers available on
request
JA-5 AI5 Analogue input No.5 (for NTC probes/0-20 mA transducers/4-
20 mA transducers); 0-5 V ratiometric transducers available on
request
JA-6 GND Analogue input common ground
JA-7 +5V Ratiometric transducer power supply
JA-8 +12V Current transducer power supply
JB Connector for digital signals
Conn. Abbrev. Description
JB-1 ID1 No. 1 digital input
JB-2 ID2 No. 2 digital input
JB-3 ID3 No. 3 digital input
JB-4 ID4 No. 4 digital input
JB-5 ID5 No. 5 digital input
JB-6 ID6 No. 6 digital input
JB-7 ID7 No. 7 digital input
JB-8 GND Digital input common connection
JC: Connection for parameter upload/download key and/or output for RS-485 and/or controller
flash memory download module.
JD: Connector for EVDFAN1 phase chopping module output (analogue output 1)
Conn. Abbrev. Description
JD-1 VDC EVDFAN1 phase chopping module power supply
JD-2 AO1 EVDFAN1 phase chopping module output
To be able to use the EVDFAN1 phase chopping module, it is essential the controller be powered using AC
current; the phase feeding the controller must be the same as that feeding the module.
JE: Connector for analogue outputs 2 and 3 (optoisolated); available on request, not available for
the open case models
Conn. Abbrev. Description (Version V+I)
JE-1 AO2 0-10 VDC
JE-2 GND Analogue output common ground
JE-3 AO3 4-20mA
Description (Version I+I)
JE-1 AO2 4-20 mA
JE-2 GND Analogue output common ground
JE-3 AO3 4-20 mA
Description (Version V+V)
JE-1 AO2 0-10 VDC
JE-2 GND Analogue output common ground
JE-3 AO3 0-10 VDC
